B4046707 Bottom part L flat, version I

B4046707

Bottom part L flat, version I

Assembly unit: unique variety of applications - mobile / desk-top and wall mounted. With screw pillars for PCB fixing. End piece for bottom part required - depending on the application - battery compartment and lid / bottom panel with handle recess / bottom panel with snap-in strips, base (desk-top), base (station for mobile cases) or base (desk-top/wall) can be assembled - see separate articles.

Version

Suitable for mounting cover or aluminum front panel (sep. article)

Supply

1 bottom part flat

  • Components/Accessories
  • View Customizing Options

Mobile with battery compartment

Mobile without battery compartment

Mobile with station

Mobile / Wall

Desk-top (screw-type connection)

Desk-top / Wall

Installation

Customizing options for B4046707

What else do you need to create your own personal product? We can supply our enclosures and tuning knobs fully modified to suit your electronic components and design requirements. Please advise for anything else we can do for you.

  • Technical Data
  • Drawings / Info
  • Purchasing Data
Protection class
IP 54 opt.
Sealings (accessories) as well as system components to complete required
Color
off-white RAL 9002
The degree(s) of protection listed refer to the empty standard enclosures (without any modifications) and are in compliance with the EN 60529 standard.
Width
10.827″
275 mm
Depth
7.677″
195 mm
Height
1.043″
26.5 mm
Please take the dimensions from current parts. These are subject to material- and manufacturing-specific tolerances.

Assembly Instructions (Group)

Drawings (Discrepancies depend on material-specific manufacturing tolerances, e.g. DIN EN 16742)

3D-Models (Discrepancies depend on material-specific manufacturing tolerances, e.g. DIN EN 16742)

Weight/1 part
175 g
Customs tariff number
(OKW product)
39269097
Country of manufacture
Germany
